Do you know the importance of the electrostatic screen in ultra-insulated transformers?
These are copper electrostatic screens placed between the primary and secondary windings and their importance is due to their dual function:
- 1
We reinforce the insulation between the primary and secondary by their connection to earth. In this way, if there is a leakage between the primary and secondary when this screen is placed between them, this leakage will be diverted to earth and the load will be protected.
- 2
The disturbances that may come from the mains are filtered:
– 1 screen: attenuation at 10 KHz of 65 dB.
– 3 screens: attenuation at 10 KHz of 80 dB.
The POLYLUX range of single-phase transformers includes 1 or 3 electrostatic screens to choose from depending on the type of mains disturbances.
Find out more about our ultra-insulated transformers.
